CellarPro 1800XTSr Cooling System - CP-SC-1800-XTSR-ECX-110

With the power of our 1800XTS cooling unit, the 1800XTSr has reversed the location of its airflows, making it perfectly designed for built-in or above-the door installations.

Dimensions:

18w x 19 1/2d x 10 1/2h (in)

Ultra-Quiet Operation (< 50 dBA)

Designed for wine cellars up to 400 cu ft (min. R-19)


Although the cooling units are rated for various size rooms, the thermal load may require a larger sized cooling unit.  Thermal load may be affected by glass in the cellar, room positioning or other factors.  Please let a Rosehill Wine Cellar rep make some suggestions for you if needed.

CellarPro's 1800XTSr-ECX cooling unit (1/4 Ton Nominal) draws inspiration from our 1800XTS cooling unit, then repositions the hot side airflows to the front of the unit, and the cold side airflows to the bottom of the unit, making it ideal for built-in and above-the-door installations that require venting at the front of the unit.

*Assuming R19 insulation throughout the cellar, 55F inside the cellar and 85F outside the cellar.

The cooling unit plugs into a standard wall outlet. The components of the cooling unit draw 3 amps, and the electric outlet on the side of the cooling unit also is rated for 3 amps. We recommend using a surge protector rated at 15 amps or more.

Specifications

Power/Rating:
115V AC / 60 Hz
Compressor Amps:
- Running: 3.7 Amps
- Startup: 22.2 Amps
- Total Watts: 440
- Required: Dedicated 15-Amp Circuit
- Recommended: Surge Protector
Decibels: 50 dBA

BTUH @ 55F: 1,886

Manuals

Cellar Pro 1800 Owner's Manual
Cellar Pro 1800 XTSr Owner’s Manual
Cellar Pro 1800 Configuration Options
Cellar Pro Cooling Systems - Specs
Cellar Pro Cooling System 1800H Houdini - Specs
Cellar Pro Cooling System 1800H Houdini - Configuration Options
Cellar Pro Cooling System 1800H Houdini - Owners Manual
Comparison chart of Features, Performance, Design, and Components

Mounting Guide (Clips)
Mounting Guide (Shelf)
Mounting Guide, Clips (1800 XTSr)
Mounting Guide, Shelf (1800 XTSr)

Front, Rear and Sides Dimensions
Top Dimensions
Bottom Dimensions
