John Boos UBS3-2136 3-Compartment Underbar Sink - JBUBS32136

John Boos UBS3-2136 3-Compartment Underbar Sink - JBUBS32136

When you purchase the John Boos UBS3-2136, you are investing in a reliable 3-compartment sink. It has three 10” wide x 14” front-to-back x 10” deep compartments. Each has a set of removable splash mount faucet holes with 4” centers to accommodate a variety of faucet types (faucet not included). The 1-1/2” drains and overflow stand pipes keep your plumbing working reliably.

The UBS3-2136 is made of stainless steel. This 18/300 stainless steel build ensures longevity. It also makes it simple to maintain. Just wipe it clean! The 3” backsplash also improves the sanitation of surrounding areas by keeping spills and splashes confined to the sink and not on the walls. This prevents stains and potential water damage.

The underbar sink unit is NSF certified for commercial applications.

Features

• ALL 18 GAUGE STAINLESS STEEL CONSTRUCTION
• TYPE 300 STAINLESS STEEL WITH #4 POLISH, SATIN FINISH
• STANDARD PRE-DRILLED HOLES ON SIDES FOR ATTACHING ADJACENT UNITS TOGETHER
• REMOVABLE FAUCET PLATES WITH 4” ON-CENTER SPLASH MOUNT FAUCET HOLES
• REMOVABLE PERFORATED DRAINBOARD INSERTS FOR INCREASED AIR CIRCULATION
• CREASED DRAINBOARDS FOR IMPROVED DRAINAGE
• STAINLESS STEEL 1-1/4” FRONT TO BACK BRACING
• FABRICATED SINK BOWL: 14” X 10” X 10” DEEP
• BOLT ON 1-5/8” STAINLESS STEEL LEGS FOR FAST INSTALLATION
• 1” ADJUSTABLE STAINLESS STEEL BULLET FEET
• Z-CLIP TO MOUNT TO WALL
• BOLT TO ADJACENT UNDERBAR PIECE
• 1-7/8” DRAIN WITH BASKET
• 1-1/2” NPS DRAIN CONNECTION

Specifications

What our Experts Think

• Efficient Three-Compartment Design – The John Boos UBS3-2136 underbar sink features three spacious compartments, each measuring 10" wide x 14" front-to-back x 10" deep. This configuration facilitates efficient washing, rinsing, and sanitizing processes, streamlining kitchen operations.

• Durable Stainless Steel Construction – Crafted from 18-gauge, 300-series stainless steel, this sink ensures longevity and resistance to corrosion, making it a reliable choice for high-demand commercial kitchens.

• Compact and Functional Design – With overall dimensions of 36" width x 21" depth x 32-1/2" height, the sink is designed to fit comfortably underbar, optimizing space without compromising functionality

• Convenient Faucet Installation – Equipped with a set of removable splash-mount faucet holes with 4" centers, the sink allows for easy installation of compatible faucets, enhancing user convenience.

• Overflow Protection – Includes 1-1/2" drains with overflow standpipes (PB-OVF-BS), providing an added layer of safety by preventing overflows during high-volume use.

Q&A

Q: What are the dimensions of the John Boos UBS3-2136 underbar sink?

 A: The sink has an overall size of 36 inches in width, 21 inches in depth, and 32.5 inches in height. Each of the three compartments measures 10 inches in width, 14 inches in front-to-back length, and 10 inches in depth.

Q: What materials is the John Boos UBS3-2136 sink made from?

A: It is constructed from 18-gauge type 300-series stainless steel, known for its durability and resistance to corrosion.

Q: Does the sink come with faucet holes?

 A: Yes, the sink includes a set of removable splash mount faucet holes with 4-inch centers, allowing for flexible faucet installation.

Q: Are drainboards included with this sink model?

A: The UBS3-2136 model does not come with drainboards. However, similar models like the UBS3-2136-X include drainboards. It's important to verify the specific model features when making a selection.

Q: What type of legs and bracing does the sink have?

 A: The sink is equipped with stainless steel legs and side bracing for enhanced stability. It also features adjustable stainless steel bullet feet to accommodate uneven floor surfaces.

Q: Does the sink have a backsplash?

A: Yes, it includes a 3-inch high backsplash to help contain splashes and maintain a clean work area.

Q: What drain connections are provided with the sink?

 A: The sink comes with 1.5-inch drains and overflow standpipes (PB-OVF-BS) to prevent water overflow.

Q: Can this sink be mounted or is it freestanding?

A: The sink is designed for underbar installation, typically mounted beneath a countertop. It includes pre-drilled holes for attaching adjacent units together, allowing for flexible installation options.

Q: Does the sink come fully assembled?

 A: Yes, the sink arrives fully assembled, facilitating quick and easy installation in your establishment.

Maintenance Tips

• Dimensions: 36" Width x 21" Depth x 32.5" Height

• Compartment Size: Each of the three compartments measures 10" Width x 14" Front-to-Back x 10" Depth

• Material: Constructed from 18-gauge, 300-series stainless steel with a satin finish

• Backsplash: Equipped with a 3" high backsplash to reduce splatter

• Faucet Holes: Comes with a set of removable splash mount faucet holes with 4" centers (faucets sold separately)

• Drains: Includes 1-1/2" drains with overflow stand pipes (PB-OVF-BS)

• Legs and Bracing: Features stainless steel legs and side bracing with adjustable stainless steel bullet feet

• Certifications: NSF certified for safety and quality
